基本细节:DS200DTBAG1AAA 数字触点接线板 具有五个跳线
数字触点接线板由通用电气生产，属于 Mark V 系列，DS200DTBAG1AAA具有两个接线端子，最多可连接 95 根电线。该装置还具有五个跳线和两个 2 针连接器。接线端子连接信号线，用于发送和接收驱动器使用的信息。GE数字接触端子板DS200DTBAG1AAA最多需要190根电线，因此您必须注意可能对其他组件和电路板造成的损坏。螺丝刀用于松开端子以移除电线，这意味着卸载时可能会击中或划伤其他组件。为防止这种情况，请用一只手将螺丝刀引导到要松开的端子。
当您从DS200DTBAG1AAA上取下信号线时，请尝试将它们移到一侧并避开其他板。如果可能，请在安装更换板之前重新安装信号线，以限制损坏驱动器中易碎板的机会。如果可以连接电线，请仅从侧面握住电路板并用两只手。小心地将电路板放入机柜中，并将孔与要安装电路板的机架上的孔对齐。进行更换时，必须佩戴腕带并将腕带的末端连接到未涂漆的金属结构上。
将 DS200DTBAG1AAA 型号连接到 Mark V DS200 系列中的其他型号时，使用了四个连接。可用的连接有 J12、JQR、JQS/T 和 JY;所有这些连接都有其特定的功能
DS200DTBAG1AAA
Manufactured by General Electric and belonging to the Mark V series, the DS200DTBAG1AAA features two terminals that can connect up to 95 wires. The device also has five jumpers and two 2-pin connectors. Terminals connect signal cables to send and receive information used by drivers. The GE digital contact terminal board DS200DTBAG1AAA requires up to 190 wires, so you must be aware of possible damage to other components and circuit boards. The screwdriver is used to loosen the terminal to remove the wire, which means it could hit or scratch other components when unloading. To prevent this, use one hand to guide the screwdriver to the terminal you want to release.
When you remove the signal wires from the DS200DTBAG1AAA, try to move them to the side and away from the other boards. If possible, reinstall the signal cable before installing the replacement board to limit the chance of damaging the fragile board in the drive. If you can connect wires, hold the board only from the side and use both hands. Carefully place the board into the cabinet and align the holes with the holes in the rack where the board is to be mounted. When making a replacement, you must wear the wristband and attach the end of the wristband to an unpainted metal structure.
When connecting the DS200DTBAG1AAA model to other models in the Mark V DS200 series, four connections are used. Available connections are J12, JQR, JQS/T and JY; All of these connections have specific functions
