基本细节:IC698PSD300 电源模块 跟踪操作过程中的问题和问题
IC698PSD300模块是GE发那科在Rx7i PACsystem系列中制造的电源模块。它的额定功率为 300 瓦，额定电压为 24 伏直流电。它是一种大容量电源单元，与 Rx7i PACsystem 系列 PLC 组件兼容。电源单元的浪涌电流最大为 100 安培。从输入到所有输出的隔离为 250 伏交流电连续，1500 伏交流电持续 1 分钟。电源具有大量功能。它是智能的，并且具有多种安全功能。它具有诊断功能，可以跟踪操作过程中的问题和问题。它提供过热、过流和不同故障条件的保护。
IC698PSD300模块配备 3 个 LED，可显示不同的操作更新。这些 LED 与电源中的气流传感器一起工作。可以使用位于电源上的跳线启用或禁用气流传感器。电源模块可以很容易地安装在左侧机架的插槽 0 中。IC698PSD300模块的环境温度是通过使用安装在机架上的风扇的强制风冷方法来保持的。环境温度应设置在 0 到 60 摄氏度之间，以便在空气冷却额定值为 70 CFM 的情况下全面运行。为保护设备免受系统噪音的影响，应将其正确接地并固定安装螺钉。电源模块的正面有铜输入端子。
该电源模块为RX7i背板模块提供逻辑电平的时序信号。它还提供过压故障条件、过流和过温保护。强大的托盘风扇将空气强制送入电源的引擎，从而促进了冷空气的供应。该风扇安装在机架底部。IC698PSD300还有一个气流传感器，可以检测风扇故障或空气堵塞。如果电源感应到气流中断，它会关闭所有输出并打开超温LED指示灯(红色)。当内部温度降低到工作水平时，电源会自动从这种状态中恢复。
IC698PSD300
The IC698PSD300 module is a power module manufactured by GE Fanuc in the Rx7i PACsystem family. It has a power rating of 300 watts and a rated voltage of 24 volts DC. It is a high capacity power supply unit compatible with Rx7i PACsystem series PLC components. The inrush current of the power supply unit is up to 100 amps. The isolation from the input to all outputs is 250 volts AC continuously and 1500 volts AC lasts for 1 minute. The power supply has a large number of functions. It is smart and has multiple security features. It has diagnostic capabilities to track problems and issues during operation. It provides protection against overheat, overcurrent and different failure conditions.
The IC698PSD300 module is equipped with 3 leds to display different operational updates. These leds work with airflow sensors in the power supply. The airflow sensor can be enabled or disabled using a jumper located on the power supply. The power module can be easily installed in slot 0 of the left rack. The ambient temperature of the IC698PSD300 module is maintained by a forced air cooling method using a fan mounted on the rack. The ambient temperature should be set between 0 and 60 degrees Celsius for full operation with an air cooling rating of 70 CFM. To protect the device from system noise, it should be properly grounded and secured with mounting screws. The front side of the power module has copper input terminals.
The power module provides sequential signals for the logic level of the RX7i backplane module. It also provides protection against overvoltage failure conditions, overcurrent and overtemperature. Powerful tray fans force air into the power supply’s engine, which facilitates the supply of cold air. The fan is installed at the bottom of the rack. The IC698PSD300 also has an air flow sensor that can detect fan failure or air blockage. If the power supply senses a disruption in airflow, it turns off all outputs and turns on the overtemperature LED indicator (red). When the internal temperature drops to the working level, the power supply automatically recovers from this state.
