基本细节:IC670ALG310 电压源模拟输出模块 用户可以针对不同事件设置警报
IC670ALG310模块是电压源模拟输出模块。它设计有 8 个不同的电压输出通道，可根据操作员的配置自动缩放。该模块从连接到它的总线接口单元获取输入，并增强校准数据，并将数据转换为-10至+10 V范围内的输出电压。IC670ALG310输出模块具有增强的诊断功能。它可以轻松检测量程外和量程不足的情况、用户功率损失和未校准的模块。输出模块还具有警报功能，用户可以针对不同事件设置警报。当输出值不满足模块最大或最小输出设置的 50 毫伏要求时，模块会将其视为低于量程和超过量程。
IC670ALG310输出模块体积小巧，适合狭小空间。对于输入数据，需要 0 到 8 个字的模拟输出数据，0 到 3 字节的模块和通道状态输入数据，以及 0 到 2 字节的输出数据来清除警报。所有数据交换都在输出模块和总线接口单元之间进行。IC670ALG310输出模块具有“通道活动”功能，允许操作员将单个通道配置为活动或非活动。该模块还具有本地输出默认功能，有助于将数据配置为默认设置，或将总线接口单元中的模块数据配置为零。该模块从总线接口吸收 170 毫安电流。模块分辨率为14位，量级数据大小为14位
IC670ALG310
The IC670ALG310 module is a voltage source analog output module. It is designed with 8 different voltage output channels that can be automatically scaled according to the operator’s configuration. The module takes inputs from the bus interface unit connected to it and enhances the calibration data and converts the data into an output voltage in the range -10 to +10 V. The IC670ALG310 output module has enhanced diagnostic capabilities. It easily detects out-of-range and under-range conditions, user power losses and uncalibrated modules. The output module also has an alert function, which allows users to set alerts for different events. When the output value does not meet the 50 millivolts requirement of the module’s maximum or minimum output setting, the module will treat it as below range and over range.
The IC670ALG310 output module is compact and suitable for tight Spaces. For input data, 0 to 8 words of analog output data, 0 to 3 bytes of module and channel status input data, and 0 to 2 bytes of output data are required to clear the alarm. All data exchange takes place between the output module and the bus interface unit. The IC670ALG310 output module has a “channel activity” function that allows operators to configure individual channels as active or inactive. The module also has a local output default that helps to configure data to default Settings, or to configure module data in the bus interface unit to zero. The module absorbs 170 mA from the bus interface. The module resolution is 14 bits and the magnitude data size is 14 bits
如果您需要查询或购买，请将产品型号发送到我的电子邮件或直接致电我
销售经理:何经理
手机: + 86 18005021035
邮箱: 18005021035@163.com
与成都阳光熹禾合作我们提供一流的服务，实现更快的速度，交付多样化的零件!
1.在24小时内及时回复您
2.交货时间快
3.最好的服务，合理的价格
4.在生产线上工作多年，有良好的口碑
