IC697MDL653 GE 离散输入模块 逻辑控制器

IC697MDL653是90-70系列24 VDCE/负逻离散输入模块。它具有四(4)组/(8)通道中的三十二(32)个离散输入通道，每个通道接受-3至+30 VDC的输入电压范围以及额定电压下10.0 mA的输入电流。
IC697MDL653该模块的每个输入通道都具有1 ms或10 ms的输入延时间，软件可配置该模块从5VDC总线汲取总计300 mA的电流，其设计也与VME标准C1兼容。该模块的立通道与背板的隔离度为1500 V，组间隔离度为500 VDCC697MDL653支持正逻和负逻接线。由于每输入组都配有的公共端子，因此组级别的接线置可能不同。对于负逻辑，正极线端接到公共端子，负极线将电压信号传送到输入通道。正逻辑接线方法与负逻接线方法相反。该模块从5VDC总汲取总计300 mA电流，其设计也与VME标准C1兼容。该模块的立通道与查板的隔离度为1500V，组间隔离度为500 VDC。IC697MDL653支持正逻辑和负逻辑接线。由于每个输入组都配有的公共端子，因此组级别的接线配置可能不同。

IC697MDL653

The IC697MDL653 is a 90-70 series 24 VDCE/ Negative Logic discrete input module. It has thirty-two (32) discrete input channels in four (4) groups /(8) channels, each accepting an input voltage range of -3 to +30 VDC and an input current of 10.0 mA at rated voltage.
IC697MDL653 The module has an input delay of 1 ms or 10 ms per input channel, the software can configure the module to draw a total of 300 mA of current from the 5VDC bus, and its design is also compatible with the VME standard C1. The isolation between the vertical channel and the backplane of the module is 1500 V, and the inter-group isolation is 500 VDCC697MDL653. Positive and negative logic connections are supported. Because each input group is equipped with a common terminal, the wiring at the group level may differ. For negative logic, the positive line is connected to the common terminal, and the negative line transmits the voltage signal to the input channel. The positive logic connection method is the opposite of the negative logic connection method. The module draws a total of 300 mA from 5VDC and is also designed to be compatible with the VME standard C1. The isolation between the vertical channel and the board of the module is 1500V, and the isolation between the groups is 500 VDC. The IC697MDL653 supports positive and negative logic connections. Because each input group is equipped with a common terminal, the wiring configuration at the group level may be different.

IC697MDL653
